View Manual: Data Security Model

View Purpose

To inform stakeholders regarding the security and responsibilities of the data assets in a department in order to improve data accountability

A model that defines the security classification of Data Subjects and the roles in the organisation that need access thereto.

Guidelines for the modelling requirements

Name and Description must be completed for all classes shown
If no additional slots are indicated, then just name and description are required
Mandatory slots are shown in red, these are required for the view to work
Mandatory slots with an option, i.e. Individual Role OR Group Role, are shown in green, these are required for the view to work
Optional slots are shown in black. The report will work without these but there may be some blank fields.
The "classified as" slot is automatically completed except where noted

Navigation	Essential Class	Additional Slots	Notes
Information / Conceptual	Data Subject	Realised by data Objects
Information / Logical	Data Object	Data Subject
Information / Logical	Data Object	Data Object Stakeholders
Business/Logical	Business Role / Individual OR Group
EA Support / Security Management	Security Policy	Policy Actors	Populate with Business Role
		Policy for Action
		Policy Applies to Resources	Populate with Data Object
EA Support / Security Management	Security Classification	Classified Information Resources
EA Support / Data Management	Data Management Policy	Data Management Responsibility	Populate with a Data Stakeholder role - see Report set up instructions
		Managed Data Object
		Responsible Roles

This view needs all the different types of 'Data Stakeholder' to be defined and added up front.
To do this:-
- Define all the different types of Data Stakeholder you have, i.e. Data Owner, Data Custodian, Data Quality Manager etc.
- Go to Business Layer/Business Conceptual/Business Role Type and CREATE a new instance of a Business Role Type.
- The name must be ADDED as Data Stakeholder.
- Click CREATE in the Is Realised by Role slot, select Individual Business Role and ADD the name of the new role, i.e. Data Owner
